Exaton 10SW is a chromium-compensating agglomerated flux giving good slag removal and a fine bead appearance. It is suitable for welding with wire and strip electrodes of the chromium & chromium-nickel and chromium-nickel-molybdenum steel types either with or without niobium. Exaton 10SW is an all round flux which can be used for many applications varying from surfacing continuous caster rolls to large components in chemical plants.

Exaton 15W is a basic welding flux for submerged arc welding giving good slag removal and a fine bead appearance. Its relatively high basicity makes it suitable for joining of austenitic and duplex stainless steel when high impact strength is desired.

Exaton 16.5.1 is a filler material for joining EN 1.4418 and similar steels. It is also used for overlay welding. The weld metal has excellent resistance to cavitation and is used typically for shafts, propellers, pumps and valves in for example, hydro power generation. It is used for SAW welding.

16.5.1 is a filler material for joining EN 1.4418 and similar steels. It is also used for overlay welding. The weld metal has excellent resistance to cavitation and is used typically for shafts, propellers, pumps and valves in for example, hydropower generation.

19.12.3.L is used for welding of austenitic stainless alloys of 18% Cr – 8% Ni and 18% Cr – 10% Ni – 3% Mo-types, stabilized or non-stabilized, e.g. ASTM 316, 316L and 316Ti as well as 304, 304L, 321 and 347, used for service temperatures up to 400°C (750°F). It is also used for Cr steels with max. 19% Cr. It is used for MIG/MAG welding.

Exaton 19.12.3.L is used for welding of austenitic stainless alloys of 18% Cr – 8% Ni and 18% Cr – 10% Ni – 3% Mo-types, stabilized or non-stabilized, e.g. ASTM 316, 316L and 316Ti as well as 304, 304L, 321 and 347, used for service temperatures up to 400°C (750°F). It is also used for Cr steels with max. 19% Cr.

19.12.3.L is used for welding of austenitic stainless alloys of 18% Cr – 8% Ni and 18% Cr – 10% Ni – 3% Mo-types, stabilized or non-stabilized, e.g. ASTM 316, 316L and 316Ti as well as 304, 304L, 321 and 347, used for service temperatures up to 400°C (750°F). It is also used for Cr steels with max. 19% Cr.It is used for TIG-welding.

Exaton 19.12.3.L is a chromium-nickel-molybdenum strip electrode used for electro-slag welding (ESW) or submerged arc welding (SAW) to deposit a second layer corrosion resistant alloy of 19%Cr/12%Ni/3%Mo composition on carbon- and low alloyed steels. The buffer layer is deposited using an over-alloyed consumable, such as 21.13.3.L, 22.11.L or 24.13.L.

19.12.3.L CRYO is a filler material for joining austenitic stainless steels, e.g. ASTM 316, 316L, as well as 304, 304L, for cryogenic applications and meets the requirements of ASME Section VIII, Division 1, UHA 51 ((a) (4) (-a) (-1)) and others. It is used for service temperatures down to -269ºC (-452ºF), and ferritic or martensitic stainless steels, with maximum 19% Cr. It is used for MIG/MAG welding. The grade has been specifically developed for welding in cryogenic applications, typically: manufacturing of dewars, containers, tanks, cryostats, and transfer systems for transportation and storage of LNG, LPG, liquid nitrogen and liquid helium. The chemical composition is optimized for cryogenic applications in terms of impact strength and other characteristics. It has controlled chemical composition and ferrite content for resistance to microfissuring, and balanced minor additions of certain elements for optimum arc stability and wetting characteristics. Impurity levels are lower in the consumable in order to reduce the risk of hot cracking and to obtain the best arc stability, fluidity, low spatter and wetting properties.

Exaton 19.12.3.L CRYO is a filler material for joining austenitic stainless steels, e.g. ASTM 316, 316L, as well as 304, 304L, for cryogenic applications and meets the requirements of ASME Section VIII, Division 1, UHA 51 ((a) (4) (-a) (-1)) and others. It is used for service temperatures down to -269ºC (-452ºF), and ferritic or martensitic stainless steels, with maximum 19% Cr. The grade has been specifically developed for welding in cryogenic applications, typically: manufacturing of dewars, containers, tanks, cryostats, and transfer systems for transportation and storage of LNG, LPG, liquid nitrogen and liquid helium.

19.12.3.L CRYO is a filler material for joining austenitic stainless steels, e.g. ASTM 316, 316L, as well as 304, 304L, for cryogenic applications and meets the requirements of ASME Section VIII, Division 1, UHA 51 ((a) (4) (-a) (-1)) and others. It is used for service temperatures down to -269ºC (-452ºF), and ferritic or martensitic stainless steels, with maximum 19% Cr. 19.12.3.L CRYO is available as wire and rods for MIG/MAG, TIG, plasma arc and submerged arc welding (SAW). The grade has been specifically developed for welding in cryogenic applications, typically: manufacturing of dewars, containers, tanks, cryostats, and transfer systems for transportation and storage of LNG, LPG, liquid nitrogen and liquid helium. The chemical composition is optimized for cryogenic applications in terms of impact strength and other characteristics. It has controlled chemical composition and ferrite content for resistance to microfissuring, and balanced minor additions of certain elements for optimum arc stability and wetting characteristics. Impurity levels are lower in the consumable in order to reduce the risk of hot cracking and to obtain the best arc stability, fluidity, low spatter and wetting properties. It is used for TIG-welding.

Exaton 19.12.3.LR is a chromium-nickel-molybdenum covered electrode with rutile coating for welding of low carbon, molybdenum alloyed, austenitic stainless steels of 316L (1.4436) type. Exaton 19.12.3.LR is used for welding steel of the types ISO: 1.4401, 1.4404, 1.4435, 1.4436, 1.4571 and ASTM: 316, 316L, 316LN, 316H and 316Ti. In cases where creep strength is of secondary importance, Exaton 19.12.3.LR is suitable for welding of corresponding stabilized austenitic steels. When a weld metal similar to the parent metal is not required, Exaton 19.12.3.LR can be used for welding ferritic and martensitic steels.

Exaton 19.12.3.LSi is used for welding of austenitic stainless alloys of 18% Cr – 8% Ni and 18% Cr – 10% Ni – 3% Mo-types, stabilized or non-stabilized, e.g. ASTM 316, 316L and 316Ti as well as 304, 304L, 321 and 347, for service temperatures up to 400°C (750°F). It is also used for welding of stainless Cr-steels with max 19% Cr.

19.12.3.LSi is used for welding of austenitic stainless alloys of 18% Cr – 8% Ni and 18% Cr – 10% Ni – 3% Mo-types, stabilized or non-stabilized, e.g. ASTM 316, 316L and 316Ti as well as 304, 304L, 321 and 347, for service temperatures up to 400°C (750°F). It is also used for welding of stainless Cr-steels with max 19% Cr. 19.12.3.LSi is particularly suited for MIG/MAGwelding but can also be used for TIG and PAW. It is used for TIG-welding.

Exaton 19.12.3.LSiMo is used for welding of austenitic stainless alloys of 18% Cr – 8% Ni and 18% Cr – 10% Ni – 3% Mo-types, stabilized or non-stabilized, e.g. ASTM 316, 316L and 316Ti as well as 304, 304L, 321 and 347, for service temperatures up to 400°C (750°F). It is also used for welding of stainless Cr-steels with max 19% Cr. Exaton 19.12.3.LSiMo is particularly suited for GMAW, but can also be used for automated GTAW and plasma welding. The critical pitting temperature, CPT, according to ASTM G150 (1°C of accuracy) can be as high as 39°C compared to standard 316LSi, which achieved maximum 29°C during the benchmark. The results were achieved with GMAW, but are expected to be on the same level or better for GTAW.

Exaton 19.12.3.LSiMo is used for welding of austenitic stainless alloys of 18% Cr – 8% Ni and 18% Cr – 10% Ni – 3% Mo-types, stabilized or non-stabilized, e.g. ASTM 316, 316L and 316Ti as well as 304, 304L, 321 and 347, for service temperatures up to 400°C (750°F). It is also used for welding of stainless Cr-steels with max 19% Cr. The alloy has increased corrosion resistance compared to standard 316LSi due to its guaranteed high Mo content of around 2.9 %. The critical pitting temperature, CPT, according to ASTM G150 (1°C of accuracy) can be as high as 39°C compared to standard 316LSi, which achieved maximum 29°C during the benchmark.
